MXD8625C Datasheet Preview — Preview of MXD8625C PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	MXD8625C
Manufacturer	Maxscend
File Size	522.04 KB
Description	SPDT Switch
Datasheet	MXD8625C-Maxscend.pdf

MXD8625C Product details

Description

The MXD8621C is a Single-Pole, Double-Throw (SPDT) LTE/WCDMA/GSM receive switch. GSM/WCDMA/

Features

Broadband frequency range: 0.1 to 3.0 GHz.
Low insertion loss: 0.45 dB @ 2.7 GHz.
High isolation: 25 dB up to 2.7 GHz.
P0.1dB 29dBm.
No external DC blocking capacitors required.
Single GPIO control line with VDD voltage regulator: VCTL= 1.6 to 3.00 V VDD= 2.5 to 3.00 V.
Small, 6-Lead DFN, 400 um pitch (1.1mm x 0.7mmx 0.45 mm) package Functional Block Diagram and Pin Function RF1 RF2 ANT Logic and Supply VDD V1 1 6 RF2 V1 2 5 GND ANT 3 4 RF1 V.
