MXD8680 Datasheet, Switch, Maxscend

MXD8680 Features

• Switch
• Excellent insertion loss - 0.6 dB Insertion Loss at 2.7GHz
• Multi-Band operation 100MHz to 3000MHz
• Compact 2mm x 2mm in QFN-14 package
• No DC block

PDF File Details

Part number:

MXD8680

Manufacturer:

Maxscend

File Size:

230.93kb

Download:

📄 Datasheet

Description:

Sp8t antenna switch. The MXD8680 is a low loss, high isolation SP8T switch with performance for antenna diversity receiving. The MXD8680 is compatible wit

MXD8680 Application

• Applications
• 2G/3G/4G antenna diversity
• Cellular modems and USB Devices Functional Block Diagram and Pin Function 14 RF6 13 RF
