SY89535L, SY89534L - PROGRAMMABLE LVPECL AND LVDS BUS CLOCK SYNTHESIZER

Micrel Semiconductor

SY89535L Datasheet Preview — This datasheet PDF includes multiple part numbers: SY89535L, SY89534L. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	SY89535L, SY89534L
Manufacturer	Micrel Semiconductor
File Size	102.35 KB
Description	PROGRAMMABLE LVPECL AND LVDS BUS CLOCK SYNTHESIZER
Datasheet	SY89534L-MicrelSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: SY89535L, SY89534L. Please refer to the document for exact specifications by model.

SY89535L Product details

Description

The SY89534L and SY89535L programmable clock synthesizers are a 3.3V, high-frequency, precision PLL-based family optimized for multi-frequency, large clock-tree applications that require the highest precision. PLL (Phase-Lock-Loop)-based synthesizer Fanout buffer Clock generator (divider) Logic translation (LVPECL, LVDS) The SY89534L and SY89535L includes a flexible input design that

Features

s Integrated synthesizer plus fanout buffers, clock dividers, and translator in a single 64-pin package s Accepts any reference input between 14MHz to 160MHz (single-ended or differential) s 33MHz to 500MHz output frequency range s LVPECL outputs (SY89534L) LVPECL and LVDS outputs (SY89535L) s 3.3V ±10% power supply s Low jitter:.
