TC1121 - 100mA Charge Pump Voltage Converter

Product Overview

Microchip

📥 Download Datasheet

TC1121 100mA Charge Pump Voltage Converter by Microchip - Datasheet Preview — Datasheet preview – TC1121

Datasheet Details

Part number	TC1121
Manufacturer	Microchip
File Size	129.46 KB
Description	100mA Charge Pump Voltage Converter
Datasheet	TC1121 Datasheet
Additional preview pages of the TC1121 datasheet.

Product details

Description

The TC1121 is a charge pump converter with 100 mA output current capability.

Features

Optional High-Frequency Operation Allows Use of Small Capacitors.
Low Operating Current (FC = Open): - 50 A.
High Output Current (100 mA).
Converts a 2.4V to 5.5V Input Voltage to a Corresponding Negative Output Voltage (Inverter mode).
Uses Only 2 Capacitors; No Inductors Required.
Selectable Oscillator Frequency: - 10 kHz to 200 kHz.
Power-Saving Shutdown Input.
Available in 8-Pin MSOP, 8-Pin PDIP and 8-Pin Small Outlin.
