CGB7004-BD Datasheet, Amplifier, Mimix Broadband

CGB7004-BD Features

• Amplifier Low Operating Voltage: 5V 32.0 dBm Output IP3 @ 850 MHz 3.6 dB Noise Figure @ 850 MHz 16.5 dB Gain @ 850 MHz 17.0 dBm P1dB @ 850 MHz Low Performance Variation Over Temperature 100% DC O

PDF File Details

Part number:

CGB7004-BD

Manufacturer:

Mimix Broadband

File Size:

433.98kb

Download:

📄 Datasheet

Description:

Ingap hbt mmic matched gain block amplifier. The CGB7004-BD is a Darlington Configured, high dynamic range, utility gain block amplifier. Designed for applications operating wit

CGB7004-BD Application

• Applications operating within the DC to 6.0 GHz frequency range, Mimix’s broadband, cascadable, gain block amplifiers are ideal solutions for transm
