PDTC114YU Datasheet, Transistor, NXP

✔ PDTC114YU Features

Built-in bias resistors R1 and R2 (typ. 10 kΩ and 47 kΩ respectively)
Simplification of circuit design
Reduces number of components and board space. APPLICATIONS

✔ PDTC114YU Application

Especially suitable for space reduction in interface and driver circuits
Inverter circuit configurations

PDF File Details

NXP manufacturer logo and representative part image

Part number:

PDTC114YU

Manufacturer:

NXP ↗

File Size:

1.27MB

Download:

📄 Datasheet

Description:

Npn transistor. NPN resistor-equipped transistor in an SC-70 (SOT323) plastic package. PINNING MGA893 - 1 PDTC114YU handbook, 4 columns 3 3 R1 1 R
