Part number: TJA1052I
Manufacturer: NXP (https://www.nxp.com/)
File Size: 281.46KB
Download: 📄 Datasheet
Description: Galvanically isolated high-speed CAN transceiver
2.1 General
* Isolator and Transceiver integrated into a single SO16 package, reducing board space
* ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 compliant
in the automotive industry, supplying the differential transmit and receive capability to a CAN protocol controller in a.
The TJA1052i is a high-speed CAN transceiver that provides a galvanically isolated interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. The TJA1052i is specifically targeted at Electric Vehicles (EV.
Image gallery
