Process 90
2N5245-47 N-Channel JFETs
General Description
The 2N5245 thru 2N5247 series of N-channel JFETs is designed for common-source or common-gate VHF/UHF amplifier, mixer and oscillator applications to 400 MHz.
Absolute Maximum Ratings
Drain-Gate Voltage Source Gate Voltage Drain Current Forward Gate Current Total Device Dissipation 25°C
(Derate above 25°C) Operating Junction Temperature
Range Storage Temperature Range Lead Temperature (1/16" from case
for 10 seconds)
30V 30V
30 mA 50 mA 360 mW
2.88mW/°C
-65 C to +150 C -65°Cto+150°C
300 C
(4.572)
D.I DO (2.5401
MAX
t a.o?5 ID.635)
0.014-0.016 I
0.150-0.1 B0
jl Qfm
|— [0.356-0.406) -»-|
-
(3.B10-4.572}
__| |__ (0 381 ,
3 LEADS
Q.10D
«-j ,'—-10° NOM,(2.
2N5245 Datasheet
