MC10EP105 - Quad 2-Input Differential AND/NAND

ON Semiconductor

MC10EP105 Datasheet Preview — Preview of MC10EP105 PDF

Datasheet Details

Part number	MC10EP105
Manufacturer	ON Semiconductor ↗
File Size	153.64 KB
Description	Quad 2-Input Differential AND/NAND
Datasheet	MC10EP105_ONSemiconductor.pdf

MC10EP105 Product details

Description

The MC10/100EP105 is a quad 2 input differential AND/NAND gate.Each gate is functionally equivalent to the EP05 and LVEL05 devices.With AC performance much faster than the LVEL05 device, the EP105 is ideal for applications requiring the fastest AC performance available.The 100 Series contains temperature compensation.

Features

275 ps Typical Propagation Delay.
Maximum Frequency > 3 GHz Typical.
PECL Mode Operating Range: VCC = 3.0 V to 5.5 V with VEE = 0 V.
NECL Mode Operating Range: VCC = 0 V with VEE =.
3.0 V to.
5.5 V.
Open Input Default State.
Safety Clamp on Inputs.
Pb.
Free Packages are Available.
http://onsemi. com.
