NB2872A - Reduced EMI Clock Synthesizer

The NB2872A by ON Semiconductor is a Reduced EMI Clock Synthesizer. Below is the official datasheet preview.

📥 Download Datasheet

Official preview page of the NB2872A Reduced EMI Clock Synthesizer datasheet (ON Semiconductor).

NB2872A Product details

Description

Supply Voltages Frequency Range Cycle to Cycle Jitter Output Duty Cycle Output Rise and Fall Times Modulation Equation Frequency Deviation VSS Specification VDD = 3.3 V " 10% 15 MHz < CLKIN < 30 MHz 300 ps (maximum) 40 / 60% (worst case) 1.1 ns (maximum) FIN/640 1.25% REFOUT XOUT XIN/CLKIN 1 2 3 6 VSS ModOUT VDD NB2872A 5 4 Figure 2. Pin Configuration Table 2. PIN DESCRIPTION Pin # 1 2 3 4 5 6 Pin Name REFOUT XOUT XIN/CLKIN VDD ModOUT VSS Type O O I P O P Buffer
