OV7661

(OV7160) CMOS VGA CameraChip

OV7661 Features

* High sensitivity for low-light operation

* Low operating voltage for embedded portable applications

* Standard SCCB interface

* VGA, QVGA, QQVGA, CIF, QCIF, QQCIF and windowed outputs with Raw RGB, RGB (GRB 4:2:2), YUV (4:2:2) and YCbCr (4:2:2) formats

* Var

OV7661 General Description

The OV7660/OV7161 CAMERACHIPTM is a low voltage CMOS image sensor that provides the full functionality of a single-chip VGA camera and image processor in a small footprint package. The OV7660/OV7161 provides full-frame, sub-sampled or windowed 8-bit images in a wide range of formats, controlled thro.

OV7661 Datasheet (567.19 KB)

Preview of OV7661 PDF

Datasheet Details

Part number:

OV7661

Manufacturer:

OmniVision

File Size:

567.19 KB

Description:

(ov7160) cmos vga camerachip.
Omni ision TM Advanced Information Preliminary Datasheet OV7660/OV7161 CMOS VGA (640x480) CAMERACHIPTM with OmniPixelTM Technology General Descript.
