3SK227 - Silicon N-Channel 4-pin MOSFET

Datasheet Summary

Features

  • 0.65±0.15 2.9±0.2 1.9±0.2 1.5.
  • 0.3 0.65±0.15 1.1.
  • 0.1 +0.2 Parameter Symbol Ratings 15 Unit V V V Drain to Source voltage VDS Gate 2 to Source voltage Drain current VG2S ID PD ±8 ±30 200 150 mA Allowable power dissipation Channel temperature Storage temperature mW °C °C 1: Source 2: Drain 3: Gate2 4: Gate1 Mini Type Package (4-pin) Tch Tstg.
  • 55 to +150 Marking Symbol: CX s Electrical Characteristics (Ta = 25°C) Parameter Symbol Drain current IDS Co.

📥 Download Datasheet

Datasheet preview – 3SK227

Datasheet Details

Part number 3SK227
Manufacturer Panasonic
File Size 186.32 KB
Description Silicon N-Channel 4-pin MOSFET
Datasheet download datasheet 3SK227 Datasheet
Additional preview pages of the 3SK227 datasheet.

📁 Similar Datasheet

  • 3SK22 - Silicon N-Channel Transistor (Toshiba)
  • 3SK222 - N-CHANNEL Si DUAL GATE MOS FIELD-EFFECT TRANSISTOR (NEC)
  • 3SK223 - N-CHANNEL Si DUAL GATE MOS FIELD-EFFECT TRANSISTOR (NEC)
  • 3SK224 - N-CHANNEL Si DUAL GATE MOS FIELD-EFFECT TRANSISTOR (NEC)
  • 3SK225 - Silicon N Channel Dual Gate MOS Type FET (Toshiba Semiconductor)
  • 3SK226 - Silicon N Channel Dual Gate MOS Type FET (Toshiba Semiconductor)
  • 3SK228 - Silicon NPN Triple Diffused (Hitachi Semiconductor)
  • 3SK206 - RF AMP. FOR UHF TV TUNER N-CHANNEL GaAs DUAL GATE MES FIELD-EFFECT TRANSISTOR 4PIN MINI MOLD (NEC)
  • 3SK207 - Silicon N Channel Dual Gate MOS Type FET (Toshiba Semiconductor)
  • 3SK231 - MOSFET (NEC)
Other Datasheets by Panasonic
  • 3SK241 - Field Effect Transistors
  • 3SK144 - Silicon N-Channel 4-pin MOS FET
  • 3SK184 - GaAs N-Channel MES FET
  • 3SK302 - Silicon N-Channel MOS
  • 3SK306 - Silicon N-Channel MOS

Full PDF Text Transcription

Click to expand full text
High Frequency FETs 3SK227 Silicon N-Channel 4-pin MOS FET For VHF amplification unit: mm 2.8 –0.3 +0.2 +0.2 M Di ain sc te on na tin nc ue e/ d s Features 0.65±0.15 2.9±0.2 1.9±0.2 1.5 –0.3 0.65±0.15 1.1 –0.1 +0.2 Parameter Symbol Ratings 15 Unit V V V Drain to Source voltage VDS Gate 2 to Source voltage Drain current VG2S ID PD ±8 ±30 200 150 mA Allowable power dissipation Channel temperature Storage temperature mW °C °C 1: Source 2: Drain 3: Gate2 4: Gate1 Mini Type Package (4-pin) Tch Tstg −55 to +150 Marking Symbol: CX s Electrical Characteristics (Ta = 25°C) Parameter Symbol Drain current IDS Conditions min 6 typ 0 to 0.1 Gate 1 to Source voltage VG1S ±8 0.4±0.2 0.
