LN1251CTR Datasheet - Panasonic

LN1251CTR Surface Mounting Chip LED

Light Emitting Diodes This product complies with the RoHS Directive (EU 2002/95/EC). LN1251CTR Surface Mounting Chip LED J Type Absolute Maximum Ratings Ta = 25°C Parameter Symbol Power dissipation PD Forward current IF Pulse forward current IFP Reverse voltage VR Operating ambient temperature Topr Storage temperature Tstg Note) : The condition of IFP is duty 10%, Pulse width 1 msec. Rating 45 15 60 4 25 to +80 30 to +85 Unit mW mA mA V °C °.

LN1251CTR Datasheet (289.64 KB)

Preview of LN1251CTR PDF
LN1251CTR Datasheet Preview Page 2 LN1251CTR Datasheet Preview Page 3

Datasheet Details

Part number:

LN1251CTR

Manufacturer:

Panasonic

File Size:

289.64 KB

Description:

Surface mounting chip led.
