LN1261CTR Datasheet - Panasonic

LN1261CTR Surface Mounting Chip LED

Light Emitting Diodes This product complies with the RoHS Directive (EU 2002/95/EC). LN1261CTR Surface Mounting Chip LED GW Type Absolute Maximum Ratings Ta = 25°C Parameter Symbol Power dissipation PD Forward current IF Pulse forward current IFP Reverse voltage VR Operating ambient temperature Topr Storage temperature Tstg Note) : The condition of IFP is duty 10%, Pulse width 1 msec. Rating 60 20 60 4 25 to +80 30 to +85 Unit mW mA mA V °C .

LN1261CTR Datasheet (296.37 KB)

Preview of LN1261CTR PDF
LN1261CTR Datasheet Preview Page 2 LN1261CTR Datasheet Preview Page 3

Datasheet Details

Part number:

LN1261CTR

Manufacturer:

Panasonic

File Size:

296.37 KB

Description:

Surface mounting chip led.
