PI3B3245 Datasheet, Nanoswitch, Pericom Semiconductor Corporation

PI3B3245 Features

• Nanoswitch ÎÎNear-Zero propagation delay ÎÎ5-ohm switches connect inputs to outputs ÎÎFast Switching Speed: 4.5ns (max.) ÎÎUltra-Low Quiescent Power (0.2μA Typical) àà Ideally suited for notebook

PDF File Details

Part number:

PI3B3245

Manufacturer:

Pericom Semiconductor Corporation

File Size:

465.78kb

Download:

📄 Datasheet

Description:

8-bit 2-port nanoswitch. Pericom Semiconductor’s PI3B3245 is a 3.3V 8-bit, 2-port bus switch designed with a low On-Resistance (5-ohm) allowing inputs to be c

PI3B3245 Application

• Applications ÎÎTTL-compatible control of inputs levels ÎÎESD protection (2kV Human Body Model and 200V Machine Model) ÎÎPackaging (Pb-free & Green):
