PL5501 Datasheet, controller equivalent, Powlicon

PL5501 Features

• Controller
• Buck-Boost Controller for Step-Up/Step-Down DC/DC Conversion
• Dynamical programming of Output current and Output voltage using PWM signal or analog signal
• 2

PDF File Details

Part number:

PL5501

Manufacturer:

Powlicon

File Size:

1.47MB

Download:

📄 Datasheet

Description:

High efficiency 4-switch buck-boost controller. PL5501 is a synchronous 4-switch Buck-Boost controller capable of regulating the output voltage at above or below the input voltage.

PL5501 Application

• Applications
• Automotive Start-Stop Systems
• Industrial PC Power Supplies
• USB Power Delivery
• Car charger
