RFHA1023 - 225W GaN WIDE-BAND PULSED POWER AMPLIFIER

RF Micro Devices

RFHA1023 Datasheet Preview — Preview of RFHA1023 PDF

Datasheet Details

Part number	RFHA1023
Manufacturer	RF Micro Devices
File Size	347.67 KB
Description	225W GaN WIDE-BAND PULSED POWER AMPLIFIER
Datasheet	RFHA1023_RFMicroDevices.pdf

RFHA1023 Product details

Description

The RFHA1023 is a 36V 225W high power discrete amplifier designed for L-Band pulsed radar, Air Traffic Control and Surveillance and general purpose broadband amplifier applications.

Features

Wideband Operation: 1.2GHz to 1.4GHz Advanced GaN HEMT Technology Advanced Heat Sink Technology Optimized Evaluation Board Layout for 50 : Operation Integrated Matching Components for High Terminal Impedances 36V Operation Typical Performance:.
RF IN VGQ Pin 1 (CUT) GND BASE RF OUT VDQ Pin 2 Functional Block Diagram Output Pulsed Power: 225W Pulse Width: 1ms, Duty Cycle 10% Smal.
