HIP2101 - High Frequency Half Bridge Driver

HIP2101 Description

DATASHEET HIP2101 100V/2A Peak, Low Cost, High Frequency Half Bridge Driver FN9025 Rev.10.00 Aug 8, 2019 The HIP2101 is a high frequency, 100V Half.
SYMBOL VDD HB HO HS HI LI VSS LO EPAD DESCRIPTION Positive Supply to lower gate drivers.

HIP2101 Features

* Drives N-Channel MOSFET Half Bridge
* SOIC, EPSOIC, QFN and DFN Package Options
* SOIC, EPSOIC and DFN Packages Compliant with 100V Conductor Spacing Guidelines of IPC-2221
* Pb-free Product Available (RoHS Compliant)
* Bootstrap Supply Max Voltage to 114VDC

HIP2101 Applications

* Telecom Half Bridge Power Supplies
* Avionics DC-DC Converters
* Two-Switch Forward Converters Active Clamp Forward Converters Related Literature For a full list of related documents, visit our website:
