ISL32614E Datasheet, Transmitters, Renesas

ISL32614E Features

• Transmitters
• Wide supply voltage range . . . . . . . . . . . . . . . . . . 1.8V to 3.6V
• Low quiescent supply current. . . . . . . . . . . . . . . . 80µA (max) - Very low shutdown

PDF File Details

Part number:

ISL32614E

Manufacturer:

Renesas ↗

File Size:

655.62kb

Download:

📄 Datasheet

Description:

Rs-485/rs-422 transmitters. PIN # 1 PIN NAME DI 2 VCC 3 DE 4 Z 5 GND 6 Y FUNCTION Driver input. A low on DI forces output Y low and output Z high.

ISL32614E Application

• Applications The ISL32613E is more slew rate limited for data rates up to 128kbps, while the less limited ISL32614E is useful for data rates up to
