SN67016 - Speech Controller

SONiX Technology Company

SN67016 Datasheet Preview — Preview of SN67016 PDF

Datasheet Details

Part number	SN67016
Manufacturer	SONiX Technology Company
File Size	103.19 KB
Description	Speech Controller
Datasheet	SN67016_SONiXTechnologyCompany.pdf

SN67016 Product details

Description

Bit0 of input port 1 Bit1 of input port 1 Bit2 of input port 1 Bit3 of input port 1 Bit0 of I/O port 2 Bit1 of I/O port 2 Bit2 of I/O port 2 Bit3 of I/O port 2 Bit0 of I/O port 3 Bit1 of I/O port 3 Bit2 of I/O port 3 Bit3 of I/O port 3 Positive power supply Oscillation component connection pin For testing only Negative power supply D/A current output 2 December 20, 2000 SN67016 Speech Controller ABSOLUTE MAXIMUM RATING Items Supply Voltage Input Voltage Operating Temperature Storag

Features

Single power supply 2.4V - 5.1V Built in a tiny controller 16 seconds voice capacity are provided One 4-bit input port and two 4-bit I/O ports are provided 64.
4 bits RAM are provided Maximum 16k program ROM is provided Readable ROM code data Built in a high quality speech synthesizer Adaptive playing speed from 2.5k-20kHz is provided Fixed current D/A output is provided to drive external connected transistor for sound output L.
