STGD3HF60HD, 600V Very Fast IGBT

The STGD3HF60HD is based on a new advanced planar technology concept to yield an IGBT with more stable switching performance (Eoff) versus temperature, as well as lower conduction losses.

The device is tailored to be a cost effective solution for motor drives.

Figure 1.

Internal schematic diagram
