STGD7NB60K N-CHANNEL IGBT

Using the latest high voltage technology based on a patented strip layout, STMicroelectronics has designed an advanced family of IGBTs, the PowerMESH ™ IGBTs, with outstanding performances. The suffix “K” identifies a family optimized for high frequency motor control applications with short circuit .

STGP7NB60K-STGP7NB60KFP-STGD7NB60K STGP7NB60KD-STGP7NB60KDFP-STGB7NB60KD N-CHANNEL 7A - 600V - TO-220/FP/DPAK/D2PAK PowerMESH™ IGBT TYPE STGP7NB60K STGD7NB60K STGP7NB60KFP STGP7NB60KD STGP7NB60KDFP STGB7NB60KD s s s s s s s VCES 600 V 600 V 600 V 600 V 600 V 600 V VCE(sat) (Typ) @125°C < < < < < < 2V 2V 2V 2V 2V 2V IC @125°C 7A 7A 7A 7A 7A 7A 3 1 2 1 3 2 TO-220 TO-220FP HIGH INPUT IMPEDANCE (VOLTAGE DRIVEN) LOW ON-VOLTAGE DROP (Vcesat) LOW GATE CHARGE HIGH CURRENT CAPABILITY OFF LOSSES I.
