STGD7NC60H N-CHANNEL 14A - 600V TO-220/DPAK Very Fast PowerMESH IGBT

STGP7NC60H - STGD7NC60H N-CHANNEL 14A - 600V TO-220/DPAK Very Fast PowerMESH™ IGBT Table 1: General .
Using the latest high voltage technology based on a patented strip layout, STMicroelectronics has designed an advanced family of IGBTs, the PowerMESH™.

STGD7NC60H_STMicroelectronics.pdf

STGD7NC60H Datasheet Preview — Preview of STGD7NC60H PDF

Datasheet Details

Part number:

STGD7NC60H

Manufacturer:

STMicroelectronics ↗

File Size:

654.97 KB

Description:

N-CHANNEL 14A - 600V TO-220/DPAK Very Fast PowerMESH IGBT

Features

* TYPE STGP7NC60H STGD7NC60HT4 s s s s www. DataSheet4U. com Figure 1: Package IC @100°C 14 A 14 A 3 1 VCES 600 V 600 V VCE(sat) (Max) @25°C < 2.5 V < 2.5 V s LOWER ON-VOLTAGE DROP (Vcesat) OFF LOSSES INCLUDE TAIL CURRENT LOWER CRES/CIES RATIO HIGH FREQUENCY OPERATION UP TO 70 KHz NEW GENERATION P

Applications

* in order to achieve very high switching performances (reduced tfall) mantaining a low voltage drop. Weight for TO-220: 1.92gr ± 0.01 Weight for DPAK: 0.38gr ± 0.01 Figure 2: Internal Schematic Diagram APPLICATIONS HIGH FREQUENCY INVERTERS s SMPS AND PFC IN BOTH HARD SWITCH AND RESONANT TOPOLOGIES
