Part number: STP60N55F3
Manufacturer: STMicroelectronics (https://www.st.com/)
File Size: 604.04KB
Download: 📄 Datasheet
Description: N-CHANNEL Power MOSFET
Type STB60N55F3 STD60N55F3 STF60N55F3 STP60N55F3 STU60N55F3
*
*
VDSS 55V 55V 55V 55V 55V
RDS(on) <10.5mΩ <10.5mΩ <10.5mΩ <10.5mΩ <10.5mΩ
ID 65A 65A 30A 65A 65A.
*
Switching application
Order codes
Part number STB60N55F3 STD60N55F3 STF60N55F3 STP60N55F3 STU60N55F3 Marking 60N.
This n-channel enhancement mode Power MOSFET is the latest refinement of STMicroelectronics' unique “Single Feature Size™“ strip-based process, which has decreased the critical alignment steps, offering remarkable manufacturing reproducibility. The o.
Image gallery
