STP6NC90Z - N-CHANNEL Power MOSFET

Name: STP6NC90Z
SKU: STP6NC90Z-505368

ST Microelectronics

📥 Download Datasheet

STP6NC90Z Datasheet Preview — Preview of STP6NC90Z PDF

Datasheet Details

Part number	STP6NC90Z
Manufacturer	STMicroelectronics
File Size	532.81 KB
Description	N-CHANNEL Power MOSFET
Datasheet	STP6NC90Z_STMicroelectronics.pdf

STP6NC90Z Product details

Description

The third generation of MESH OVERLAY™ Power MOSFETs for very high voltage exhibits unsurpassed on-resistance per unit area while integrating back-toback Zener diodes between gate and source.

Features

OF GATE-TO-SOURCE ZENER DIODES The built-in back-to-back Zener diodes have specifically been designed to enhance not only the device’s ESD capability, but also to make them safely absorb possible voltage transients that may occasionally be applied from gate to source. In this respect the Zener voltage is appropriate to achieve an efficient and cost-effective intervention to protect the device’s integrity. These integrated Zener diodes thus avoid the usage of external components. 3/13 STP6NC90Z.
