STV9325 Datasheet, Generator, ST Microelectronics

STV9325 Features

• Generator
• Power amplifier
• Flyback generator
• Stand-by control
• Output current up to 2.5 App
• Thermal protection Description The STV9325 is a vertica

PDF File Details

Part number:

STV9325

Manufacturer:

STMicroelectronics ↗

File Size:

346.51kb

Download:

📄 Datasheet

Description:

Vertical deflection booster for 2.5-apptv/monitor applications with 70-v flyback generator. The STV9325 is a vertical deflection booster designed for TV and monitor applications. This device, supplied with up to 35 V, provide

STV9325 Application

• Applications with 70 V flyback generator Features
• Power amplifier
• Flyback generator
• Stand-by control
• Output
