STV9326 Datasheet, booster equivalent, ST Microelectronics

STV9326 Features

• Booster
• Power Amplifier
• Flyback Generator
• Stand-by Control
• Output Current up to 3 App
• Thermal Protection HEPTAWATT (Plastic Package) ORDER CODE

PDF File Details

Part number:

STV9326

Manufacturer:

STMicroelectronics ↗

File Size:

533.66kb

Download:

📄 Datasheet

Description:

Vertical deflection booster. The STV9326 is a vertical deflection booster designed for TV and monitor applications. This device, supplied with up to 30 V, provide

STV9326 Application

• Applications with 60-V Flyback Generator DATASHEET Main Features
• Power Amplifier
• Flyback Generator
• Stand-by Control <
