STV9553 Datasheet (ST Microelectronics) - 12 ns TRIPLE-CHANNEL HIGH VOLTAGE VIDEO AMPLIFIER

STV9553, 12 ns TRIPLE-CHANNEL HIGH VOLTAGE VIDEO AMPLIFIER

The STV9553 is a triple-channel video amplifier designed in a 120V-high voltage technology and able to drive in DC-coupling mode the 3 cathodes of a CRT monitor.

The STV9553 supports PICTURE BOOST applications where video amplitude up to 50V or CLIPWATT 11 (Plastic Package) ORDER CODE: STV9553 PIN

STV9553 Features

* s s s s s s s s s s Triple-channel video amplifier Supply voltage up to 115 V 80V Output dynamic range Perfect for PICTURE BOOST application requiring high video amplitude Pinning for easy PCB layout Supports DC coupling (optimum cost saving) and AC coupling applications. Built-in Voltage Gain: 2
