STF26NM60N-H Datasheet, Mosfet, STMicroelectronics

STF26NM60N-H Features

  • Mosfet Type STF26NM60N-H
  • VDSS 600 V RDS(on) max < 0.165 Ω ID 20 A 100% avalanche tested Low input capacitance and gate charge Low gate input resistance 1 3 2

PDF File Details

Part number:

STF26NM60N-H

Manufacturer:

STMicroelectronics ↗

File Size:

738.46kb

Download:

📄 Datasheet

Description:

N-channel mosfet. This series of devices implements second generation MDmesh™ technology. This revolutionary Power MOSFET associates a new vertical str

Datasheet Preview: STF26NM60N-H 📥 Download PDF (738.46kb)
Page 2 of STF26NM60N-H Page 3 of STF26NM60N-H

STF26NM60N-H Application

  • Applications Description This series of devices implements second generation MDmesh™ technology. This revolutionary Power MOSFET associates a new v
