STP11NM65N

N-channel MOSFET

STP11NM65N Features

* 123 TO-220FP TO-2201 23 Order codes STF11NM65N VDS RDS(on) max. ID t(s) 123 I2PAKFP uc (TO-281) STFI11NM65N 650 V 455 mΩ 11 A STP11NM65N

* 100% avalanche tested d D(2, TAB)

* Low input capacitance and gate charge ro

* Low gate input resistance te P Applicatio

STP11NM65N General Description

O S(3) uct(s) - AM01475v1_noZen These devices are N-channel Power MOSFETs developed using the second generation of MDmesh technology. These revolutionary Power MOSFETs associate a vertical structure to the company’s strip layout to yield one of the world’s lowest on-resistance and gate charge. The.

STP11NM65N Datasheet (532.10 KB)

Preview of STP11NM65N PDF

Datasheet Details

Part number:

STP11NM65N

Manufacturer:

STMicroelectronics ↗

File Size:

532.10 KB

Description:

N-channel mosfet.
STF11NM65N, STFI11NM65N, STP11NM65N Datasheet N-channel 650 V, 425 mΩ typ., 11 A MDmesh II Power MOSFETs in TO-220FP, I²PAKFP and TO-220 packages TAB.
