VNN1NV04P-E Datasheet, MOSFET, STMicroelectronics

VNN1NV04P-E Features

Mosfet Parameter Symbol Value Max on-state resistance (per ch.) Current limitation (typ) Drain-source clamp voltage RON ILIMH VCLAMP 250 m 1.7 A 40 V
Linear current limitation

PDF File Details

Part number:

VNN1NV04P-E

Manufacturer:

STMicroelectronics ↗

File Size:

460.74kb

Download:

📄 Datasheet

Description:

Fully autoprotected power mosfet. The VNN1NV04P-E, VNS1NV04P-E are monolithic devices designed in STMicroelectronics VIPower M0-3 Technology, intended for replacement

📥 Download PDF (460.74kb)

VNN1NV04P-E Application

Applications Built in thermal shutdown, linear current limitation and overvoltage clamp protect the chip in harsh environments. Fault feedback can
