2SC5003 Datasheet - Sanken electric

2SC5003 NPN TRANSISTOR

Built-in Damper Diode sAbsolute maximum ratings (Ta=25°C) Symbol VCBO VCEO VEBO IC IB PC Tj Tstg 2SC5003 1500 800 6 7(Pulse14) 3.5 80(Tc=25°C) 150 55 to +150 Unit V V V A A W °C °C 2SC5003 (Ta=25°C) 2SC5003 100max 1max 1max 6min 8min 4 to 9 5max 1.5max 2.0max 4typ 100typ Unit µA mA mA V Conditions VCB=1200V VCB=1500V VCE=800V IEB=300mA VCE=5V, IC=1A VCE=5V, IC=5A IC=5A, IB=1.2A IC=5A, IB=1.2A IEC=7A VCE=12V, IE= 0.5A VCB=10V, f=1MHz 0.8±0.2 15.6±0.2 23.0±0.3 9.5±0.2 Equivalent.
