STK11C48 - 8K x 8 nvSRAM QuantumTrap CMOS Nonvolatile Static RAM

Datasheet Summary

Description

The Simtek STK11C48 is a fast static RAM with a nonvolatile element incorporated in each static memory cell.

The SRAM can be read and written an unlimited number of times, while independent, nonvolatile data resides in the Nonvolatile Elements.

Features

  • 25ns, 35ns and 45ns Access Times.
  • STORE to Nonvolatile Elements Initiated by Software.
  • RECALL to SRAM Initiated by Software or Power Restore.
  • 10mA Typical ICC at 200ns Cycle Time.
  • Unlimited READ, WRITE and RECALL Cycles.
  • 1,000,000 STORE Cycles to Nonvolatile Elements.
  • 100-Year Data Retention in Nonvolatile Elements.
  • Commercial and Industrial Temperatures.
  • 28-Pin 300 mil PDIP, 300 mil SOIC and 350 mil SOIC Packages.

📥 Download Datasheet

Datasheet preview – STK11C48

Datasheet Details

Part number STK11C48
Manufacturer Simtek
File Size 282.62 KB
Description 8K x 8 nvSRAM QuantumTrap CMOS Nonvolatile Static RAM
Datasheet download datasheet STK11C48 Datasheet
Additional preview pages of the STK11C48 datasheet.

📁 Similar Datasheet

  • STK11C68 - 64-Kbit (8 K x 8) SoftStore nvSRAM (Cypress Semiconductor)
  • STK11C88 - 256 Kbit (32 K x 8) SoftStore nvSRAM (Cypress Semiconductor)
  • STK1160 - USB2.0 TV Tuner/Video Capture Controller (SYNTEK)
  • STK103 - N-Channel MOSFET (SamHop Microelectronics)
  • STK1030 - AF Power Amplifier Output Stage (ETC)
  • STK1030 - (STKxxxx) Output Stage of AF Power Amp (ETC)
  • STK1035 - (STKxxxx) Output Stage of AF Power Amp (ETC)
  • STK1039 - (STKxxxx) Output Stage of AF Power Amp (ETC)
  • STK1040 - (STKxxxx) Output Stage of AF Power Amp (ETC)
  • STK1045 - (STKxxxx) Output Stage of AF Power Amp (ETC)
Other Datasheets by Simtek
  • STK11C68 - 8K x 8 nvSRAM QuantumTrap CMOS Nonvolatile Static RAM
  • STK11C68-M - CMOS NV SRAM
  • STK11C88 - 32Kx8 SoftStore nvSRAM
  • STK11C88-3 - 32K X 8 NVSRAM 3.3 V QUANTUM TRAP CMOS NONVOLATILE STATIC RAM
  • STK10C48 - 2K X 8 NVSRAM
  • STK10C68 - 8K x 8 nvSRAM
  • STK12C68 - 8Kx8 AutoStore nvSRAM
  • STK12C68-M - CMOS NV SRAM 8K X 8 AUTOSTORE NONVOLATILE STATIC RAM

Full PDF Text Transcription

Click to expand full text
STK11C48 2K x 8 nvSRAM QuantumTrap™ CMOS Nonvolatile Static RAM FEATURES • 25ns, 35ns and 45ns Access Times • STORE to Nonvolatile Elements Initiated by Software • RECALL to SRAM Initiated by Software or Power Restore • 10mA Typical ICC at 200ns Cycle Time • Unlimited READ, WRITE and RECALL Cycles • 1,000,000 STORE Cycles to Nonvolatile Elements • 100-Year Data Retention in Nonvolatile Elements • Commercial and Industrial Temperatures • 28-Pin 300 mil PDIP, 300 mil SOIC and 350 mil SOIC Packages DESCRIPTION The Simtek STK11C48 is a fast static RAM with a nonvolatile element incorporated in each static memory cell. The SRAM can be read and written an unlimited number of times, while independent, nonvolatile data resides in the Nonvolatile Elements.
