SSD1815B - LCD Segment / Common Driver

Product Overview

Solomon Systech

Part number	SSD1815B
Manufacturer	Solomon Systech
File Size	361.83 KB
Description	LCD Segment / Common Driver
Datasheet	SSD1815B Datasheet
Additional preview pages of the SSD1815B datasheet.

Dot-matrix Display with separated Icon Line, 132 x 64 + 1 Icon Line Single Supply Operation, 2.4V ~ 3.5V Minimum -12.0V LCD Driving Output Voltage Low Current Sleep Mode On-Chip Voltage Generator or External LCD Driving Power Supply Selectable 2X / 3X / 4X On-Chip DC-DC Converter On-Chip Oscillator Programmable Multiplex ratio in dot-matrix display area, 1Mux ~ 64Mux On-Chip Bias Divider Programmable bias ratio, 1/4, 1/5, 1/6, 1/7, 1/8, 1/9 8-bit 6800-series Parallel Interface, 8-bit 8080-series.
