CXG1006N - GSM900/1800/1900 SPDT TX/RX Switch

Product Overview

Sony Corporation

📥 Download Datasheet

CXG1006N GSM900/1800/1900 SPDT TX/RX Switch by Sony Corporation - Datasheet Preview — Datasheet preview – CXG1006N

Datasheet Details

Part number	CXG1006N
Manufacturer	Sony Corporation
File Size	71.21 KB
Description	GSM900/1800/1900 SPDT TX/RX Switch
Datasheet	CXG1006N Datasheet
Additional preview pages of the CXG1006N datasheet.

Product details

Description

The CXG1006N is a high power antenna switch MMIC.

Features

Single positive power supply operation.
Low insertion loss 0.5dB (Typ. ) at 2.0GHz.
High isolation 27dB (Typ. ) at 2.0GHz.
High power switching P1dB (Typ. ) 32dBm at 2.0GHz VCTL (H) = 2.0V 34dBm at 2.0GHz VCTL (H) = 4.0V.
