K2699 Datasheet - Toshiba Semiconductor

K2699, 2SK2699

2SK2699 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (π *MOSV) 2SK2699 Chopper Regulator, DC *DC Converter and Motor Driv.

datasheet Preview Page 1 from Datasheet4u.com

K2699_ToshibaSemiconductor.pdf

K2699 Datasheet Preview — Preview of K2699 PDF

Datasheet Details

Part number:

K2699

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

425.39 KB

Description:

2SK2699

Applications

* Unit: mm z Low drain
* source ON resistance : RDS (ON) = 0.5 Ω (typ. ) z High forward transfer admittance : |Yfs| = 11 S (typ. ) z Low leakage current : IDSS = 100 μA (max) (VDS = 600 V) z Enhancement mode : Vth = 2.0 to 4.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ratings (Ta = 25°C)
