TQP369184 DC-6 GHz Gain Block

The TQP369184 is a general-purpose buffer amplifier that offers high dynamic range in a low-cost surfacemount package. At 1.9 GHz, the amplifier typically provides 20.3 dB gain, +28.5 dBm OIP3, and 3.9 dB Noise Figure while drawing 45 mA current. The device combines dependable performance with consi.

TQP369184 Features

* DC-6000 MHz Flat, broadband frequency response 20.3 dB Gain @ 1.9 GHz 3.9 dB Noise Figure @ 1.9 GHz +28.5 dBm Output IP3 @ 1.9 GHz +15.5 dBm P1dB @ 1.9 GHz 50 Ohm Cascadable Gain Block Single Supply, 45 mA Curr
