QM2502M9 Dual N-Ch 20V Fast Switching MOSFETs

The QM2502M9 is the highest performance trench N-ch MOSFETs with extreme high cell density , which provide excellent RDSON and gate charge for most of the small power switching and load switch applications. The QM2502M9 meet the RoHS and Green Product requirement with full function reliability appro.

QM2502M9 Features

* z Advanced high cell density Trench technology z Super Low Gate Charge z Excellent Cdv/dt effect decline z Green Device Available Product Summery BVDSS 20V RDSON 18.5mΩ ID 11A Applications z Power management in portable and battery operated products z DC-DC Power System z Load Switch PRPAK2X5 P

QM2502M9 Datasheet (336.17 KB)
