CHS5100

DC-20GHz Reflective SPDT Switch

CHS5100 Features

* þ Broadband performance : DC-20GHz þ Low insertion loss : 2.1dB@20GHz þ High isolation : 53dB@1GHz 30dB@20GHz þ Excellent input and output matching: VSWR < 1.5:1 þ Chip size : 1,92 x 1,22 x 0.1mm Main Characteristics Tamb = +25°C Symbol Il Parameter On state insertion loss 1/9Er reur! Docu ment pri

CHS5100 General Description

The CHS5100 is a wideband monolithic FET based reflective switch manufactured on a standard power process using 0.7µm implanted active layer MESFET, via holes, air bridges and electron beam gate lithography. This wideband switch is suitable for ultra broadband ECM and EW systems. It can also be used.

CHS5100 Datasheet (115.59 KB)

Preview of CHS5100 PDF

Datasheet Details

Part number:

CHS5100

Manufacturer:

United Monolithic Semiconductors

File Size:

115.59 KB

Description:

Dc-20ghz reflective spdt switch.
