ME2306 - N-Channel MOSFET

ME2306 Description

ME2306-VB ME2306-VB Datasheet N-Channel 30-V (D-S) MOSFET www.VBsemi.com PRODUCT SUMMARY VDS (V) RDS(on) (Ω) 0.030 at VGS = 10 V 30 0.033 at VGS.

ME2306 Features

* Halogen-free According to IEC 61249-2-21 Definition
* TrenchFET® Power MOSFET
* 100 % Rg Tested

ME2306 Applications

* DC/DC Converter D G1 S2 3D Top View G S N-Channel MOSFET ABSOLUTE MAXIMUM RATINGS TA = 25 °C, unless otherwise noted Parameter Symbol Drain-Source Voltage Gate-Source Voltage Continuous Drain Current (TJ = 150 °C) Pulsed Drain Current TC = 25 °C TC = 70 °C TA = 25 °C TA = 70 °C

📥 Download Datasheet

Preview of ME2306 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
ME2306
Manufacturer
VBsemi
File Size
227.39 KB
Datasheet
ME2306-VBsemi.pdf
Description
N-Channel MOSFET
