ZXT1053AK Datasheet, D-pak, Zetex Semiconductors

ZXT1053AK Features

• D-pak
• 5 amps continuous current
• Up to 10 amps peak current
• Low equivalent on resistance
• Low saturation voltages
• High hFE (300 min @ 1A) DPAK

PDF File Details

Part number:

ZXT1053AK

Manufacturer:

Zetex Semiconductors

File Size:

136.49kb

Download:

📄 Datasheet

Description:

75v npn low saturation medium power transistor in d-pak. Packaged in the D-Pak outline this high current high gain 75V NPN transistor offers low on state losses making it ideal for use in DC

ZXT1053AK Application

• Applications
• DC - DC converters
• DC - DC modules
• Power switches
• Motor control
• Automotive circuits <
