DAC7554 Datasheet, Converter, Texas Instruments

DAC7554 Features

• Converter
• 2.7-V to 5.5-V Single Supply
• 12-Bit Linearity and Monotonicity
• Rail-to-Rail Voltage Output
• Settling Time: 5 µs (Max)
• Ultralow Glitch En

PDF File Details

Part number:

DAC7554

Manufacturer:

Texas Instruments ↗

File Size:

1.84MB

Download:

📄 Datasheet

Description:

Quad 12-bit d/a converter. The DAC7554 is a quad-channel, voltage-output DAC with exceptional linearity and monotonicity. Its proprietary architecture minimizes

DAC7554 Application

• Applications
• Portable Battery-Powered Instruments
• Digital Gain and Offset Adjustment
• Programmable Voltage and Current
