DS99R102, DS99R101 - 3-40MHz DC-Balanced 24-Bit LVDS Serializer / Deserializer

Texas Instruments

DS99R102 Datasheet Preview — This datasheet PDF includes multiple part numbers: DS99R102, DS99R101. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	DS99R102, DS99R101
Manufacturer	Texas Instruments ↗
File Size	400.41 KB
Description	3-40MHz DC-Balanced 24-Bit LVDS Serializer / Deserializer
Datasheet	DS99R101-etcTI.pdf
Note	This datasheet PDF includes multiple part numbers: DS99R102, DS99R101. Please refer to the document for exact specifications by model.

DS99R102 Product details

Description

The DS99R101/DS99R102 Chipset translates a 24bit parallel bus into a fully transparent data/control LVDS serial stream with embedded clock information.

Features

1.
2 3 MHz.
40 MHz Clock Embedded and DCBalancing 24:1 and 1:24 Data Transmissions.
User Selectable Clock Edge for Parallel Data on Both Transmitter and Receiver.
Internal DC Balancing Encode/Decode.
Supports AC-Coupling Interface with No External Coding Required.
Individual Power-Down Controls for Both Transmitter and Receiver.
Embedded Clock CDR (Clock and Data Recovery) on Receiver and No External Source of Reference Clock Needed.
