TPS3801, TPS3800 - ULTRA-SMALL SUPPLY VOLTAGE SUPERVISORS

Texas Instruments

TPS3801 Datasheet Preview — This datasheet PDF includes multiple part numbers: TPS3801, TPS3800. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	TPS3801, TPS3800
Manufacturer	Texas Instruments ↗
File Size	789.78 KB
Description	ULTRA-SMALL SUPPLY VOLTAGE SUPERVISORS
Datasheet	TPS3800-etcTI.pdf
Note	This datasheet PDF includes multiple part numbers: TPS3801, TPS3800. Please refer to the document for exact specifications by model.

TPS3801 Product details

Description

The TPS380x family of supervisory circuits monitor supply voltages to provide circuit initialization and timing supervision, primarily for DSPs and other processor-based systems.

Features

1.
2 Small, 5-Pin SC-70 (SOT-323) Package.
Supply Current of 9 mA.
Power-On Reset Generator With Fixed Delay Time.
TPS3800 = 100 ms.
TPS3801 = 200 ms.
TPS3802 = 400 ms.
Precision Supply Voltage Monitor 1.8 V, 2.5 V, 2.7 V, 3 V, 3.3 V, 5 V, and Adjustable.
Manual Reset Input (Except TPS3801-01).
Temperature Range:.
40°C to +85°C.
