2N3905 - Silicon PNP Transistor

Datasheet Summary

Features

  • . Low Leakage Current : ICEV= -50nA(Max. ), T-BEV= 50nA(Max. @ V C E=-30V, Vbe=3V . Excellent DC Current Gain Linearity . Low Saturation Voltage : V CE ( sat) =-0.4V(Max. ) @ I C =-50mA, I B =-5mA . Low Collector Output Capacitance : C b=4.5pF(Max. ) @ VCB =-5V . Complementary to 2N3903 J EDEC 1.

📥 Download Datasheet

Datasheet preview – 2N3905

Datasheet Details

Part number 2N3905
Manufacturer Toshiba
File Size 63.77 KB
Description Silicon PNP Transistor
Datasheet download datasheet 2N3905 Datasheet
