ASM5I2308A

3.3 V Zero Delay Buffer

ASM5I2308A Features

* Zero input - output propagation delay, adjustable by capacitive load on FBK input.

* Multiple configurations - Refer “ASM5P2308A Configurations “ Table. www.DataSheet4U.com

* Input frequency range: 15MHz to 133MHz ASM5P2308A allows the input clock to be directly applied t

ASM5I2308A General Description

ASM5P2308A is a versatile, 3.3V zero-delay buffer designed to distribute high-speed clocks. It is available in a 16 pin package. The part has an on-chip PLL which locks to an input clock presented on the REF pin. The PLL feedback is required to be driven to FBK pin, and can be obtained from one of t.

ASM5I2308A Datasheet (415.32 KB)

Preview of ASM5I2308A PDF

Datasheet Details

Part number:

ASM5I2308A

Manufacturer:

Alliance Semiconductor

File Size:

415.32 KB

Description:

3.3 v zero delay buffer.
