ADM202 Datasheet, Driver/receiver, Analog Devices

ADM202 Features

• Driver/receiver 120 kB transmission rate Small (0.1 µF) charge pump capacitors Single 5 V power supply Meets TIA/EIA-232-E and V.28 specifications 2 drivers and 2 receivers On-board dc-to-dc converters

PDF File Details

Part number:

ADM202

Manufacturer:

Analog Devices ↗

File Size:

337.63kb

Download:

📄 Datasheet

Description:

Cmos rs-232 driver/receiver. The ADM202 is a 2-channel RS-232 line driver/receiver pair designed to operate from a single 5 V power supply. A highly efficient on-

ADM202 Application

• Applications Computers Peripherals Modems Printers Instruments GENERAL DESCRIPTION The ADM202 is a 2-channel RS-232 line driver/receiver pair design
