HMC641ALC4 Datasheet, Switch, Analog Devices

HMC641ALC4 Features

• Switch Broadband Performance: DC - 20 GHz High Isolation: 42 dB @ 12 GHz Low Insertion Loss: 2.1 dB @ 12 GHz Integrated 2:4 TTL Decoder 24 Lead 4x4mm SMT Package: 16mm² General Description The

PDF File Details

Part number:

HMC641ALC4

Manufacturer:

Analog Devices ↗

File Size:

458.43kb

Download:

📄 Datasheet

Description:

Gaas mmic sp4t non-reflective switch. The HMC641ALC4 is a broadband non-reflective GaAs pHEMT SP4T switch in a compact 4x4 mm ceramic package. Covering DC to 20 GHz, this

HMC641ALC4 Application

• Applications The HMC641ALC4 is ideal for:
• Telecom Infrastructure
• Microwave Radio & VSAT
• Military & Space Hybrids
