HMC792ALP4E Datasheet, Attenuator, Analog Devices

HMC792ALP4E Features

• Attenuator 0.25 dB LSB Steps to 15.75 dB Power-Up State Selection High Input IP3: +53 dBm Low Insertion Loss: 1.8 dB @ 2.0 GHz TTL/CMOS Compatible, Serial, Parallel or Latched Parallel Control ±

PDF File Details

Part number:

HMC792ALP4E

Manufacturer:

Analog Devices ↗

File Size:

577.24kb

Download:

📄 Datasheet

Description:

0.25 lsb gaas mmic 6-bit digital attenuator. The HMC792ALP4E is a broadband 6-bit GaAs IC Digital Attenuator in a low cost leadless SMT package. This versatile digital attenuator

HMC792ALP4E Application

• Applications The HMC792ALP4E is ideal for:
• Cellular/3G Infrastructure
• WiBro / WiMAX / 4G
• Microwave Radio & VSAT
<
