UPB1512TU Datasheet, Prescaler, CEL

UPB1512TU Features

• Prescaler
• OPERATING FREQUENCY: fin = 5 to 13 GHz
• LOW CURRENT CONSUMPTION: ICC = 48 mA @ VCC = 5.0 V
• HIGH-DENSITY SURFACE MOUNTING: 8-pin lead-less minimold

PDF File Details

Part number:

UPB1512TU

Manufacturer:

CEL

File Size:

578.48kb

Download:

📄 Datasheet

Description:

Input divide by 8 prescaler. NEC's UPB1512TU is a silicon germanium (SiGe) monolithic integrated circuit designed as a divide by 8 prescaler IC for satellite comm

UPB1512TU Application

• Applications
• POINT-TO-POINT/ MULTI-POINT RADIOS
• VSAT RADIOS ORDERING INFORMATION PART NUMBER UPB1512TU-E2 ORDER NUMBER UPB1512T
